BAYA UMBRELLA BASES Designed by Povl Eskildsen

Material: Stainless steel andd steel See page: 256 for frame colour options

Cantilever Base Excl. Additional 76 kg | 166 lbs ACCESSORIES Square Umbrella Base
12 pcs Concrete Pavers Double Stack Plate FOR BAYA Long Stem
12”x12” | 30 cm x 30 cm for Baya Cantilever Base CANTILEVER BASE 24” x 24” | 60 cm x 60 cm
Weight Incl. Pavers: 220 kg | 484 lbs Weight: 35 kg | 77 lbs
W 32.7” 83 cm W 31.9” 81 cm Wheel Set for Cantilever Base W 23.2” 59 cm
L 39.0” 99 cm L 38.2” 97 cm L 23.2” 59 cm
H 29.1” 74 cm H 0.8” 2 cm H 20.7” 53 cm
ØD Ø2.5” Ø6 cm ØD Ø2.0” Ø5 cm
ØD W
W W ØD
H L L H L
H

Square Umbrella Base Additional 35 kg | 77 lbs ACCESSORIES Round Umbrella Base
Short Stem Double Stack Plate FOR BAYA SQUARE Long Stem
24” x 24” | 60 cm x 60 cm for Square Umbrella Bases BASES Ø24”| Ø60 cm
Weight: 35 kg | 77 lbs Weight: 27 kg | 60 lbs
W 23.2” 59 cm W 23.2” 59 cm Wheel Set for Square ØD1 Ø23.2” Ø59 cm
L 23.2” 59 cm L 23.2” 59 cm Umbrella Bases ØD2 Ø2.0” Ø5 cm
H 16.7” 43 cm H 0.8” 2 cm H 20.7” 53 cm
ØD Ø2.0” Ø5 cm
ØD1
W ØD2
W ØD
L H
H L H

Round Umbrella Base Additional 27 kg | 60 lbs ACCESSORIES Umbrella Reducer Ring
Short Stem Double Stack Plate FOR BAYA ROUND
Ø24”| Ø60 cm for Round Umbrella Bases BASES Available in stainless steel
Weight: 27 kg | 60 lbs or powder coated aluminium
ØD1 Ø23.2” Ø59 cm ØD Ø23.2” Ø59 cm Wheel Set for Round D1 Ø2.7” 7 cm
ØD2 Ø2.0” Ø5 cm H 0.8” 2 cm Umbrella Bases D2 Ø1.6” 4 cm
H 16.7” 43 cm H 0.6” 2 cm
ØD
ØD1
ØD2 D1 D2
L H
H
H
ACCESSORIES FOR BAYA UMBRELLAS AND BASES
Anchor bolts for securing single round base plate to
Optional wind stabilizer for cantilever umbrellas
concrete floors, set of 6 pcs

Protective cover for umbrellas Cast-on-site concrete base for all Baya umbrellas

Extra long bolts for triple stacked base plates, Long stem for use with cast-on-site concrete base
set of 3 pcs

Anchor bolts for securing single square base plate to
concrete floors, set of 4 pcs Short stem for use with cast-on-site concrete base
